Recogniform OCR-B SDK

SDK development tools



Other products


Recogniform OCR-B SDK

History: the OCR-B font was designed in 1968 by Adrian Frutiger for Monotype. This design pushes the limits of the data capture compared to standard fonts, but human reading is easier than in OCR-A font. OCR-B is in conformity with ISO 1073/II-1976 (E) standard, corrected in 1979 ("letterpress" design, size I).

Standard: font print size is 12 points, print density is 10 cpi.

Capability: our OCR-B recognition engine is size independent and it's able to read every font size. The basic recognized character set is made up by the following digits and symbols:
Recogniform OCR-B SDK
Accuracy: with OCR-B recognition engine, accuracy reaches 100% using good quality scanned images; if quality is low or medium, error rate will usually be less than 0.5%

Technology: our engine is based on three distinct classifiers that use different methods: artificial neural network, features extraction, statistycal matrix matching. An expert system, using fuzzy rules, reconciles all the outputs obtaining the best match.

Speed: speed is linked to cpu speed. Using Pentium processors, time performance are usually included between 50 and 150 CPS .

Input: monochrome or gray-scale bitmaps with 200 or more DPI resolution are accepted in input. The best results can be reached using gray-scale images since a binarization algorithm is internally used.

Output: output is made up by recognized characters as well as confidence levels. Placeholders are used for unrecognized or very suspicious characters.

Platform: all Windows platforms are supported.

Packaging:the engine is packaged in DLL format. The total size is less then 1 Mb. No extra file is required.

Licensing: application development requires one SDK license and application distribution requires payment of royalties.

Demo: a free of charge evaluation package is available upon request .

Prices: SDK and licenses prices are available upon request.

Examples: the following images are ALL automatically readable with 100% accuracy:
OCRB - The engine reads good quality images...
The engine reads good quality images...
OCRB - ...as well as skewed images...
...as well as skewed images...
OCRB - ...as well as dirty images...
...as well as dirty images...
OCRB - ...as well as very dark images...
...as well as very dark images...
OCRB - ...as well as very light images...
...as well as very light images...
OCRB - ...as well as noisy images !
...as well as noisy images !
Evaluation version
Through the download section you can download an evaluation version of this product.


Looking a solution ready to use capable of processing images, documents and forms contenents text lines with OCR-B characters? Choose Recogniform Reader!
To more information about Recogniform OCR-B SDK and our solution for data capture and image processing, you can send us a email to informazioni@recogniform.it or fill the below form.


Company
Title
First Name
Last Name
Address
Zip Code
State
Country
Phone
Fax
E-mail
Message

Taking note of Information of the policy of personal data (D. Lgs 30 june 2003 n.196 and subsequent amendment and additions), click on the "OK" button i consent to collect, hold, process, communicate, and if appropriate, discontinue the treatment/s of personal data that concern me, for the purposes specified in the policy.


  • SDK OCR-B - Purchase

    SDK OCR-B

    € 2.000,00 + VAT
    Purchase
  • SDK OCR-B - Runtime license - Purchase

    SDK OCR-B - Runtime license

      x   € 200,00 + VAT
    Purchase
